Underground Medium Voltage 11kv 15kv 22kv 70mm-400 Sqmm Aluminium Armoured Power Cable
Application
The cables are designed for distribution of electrical power with nominal voltage Uo/U ranging from 1KV to 35KV and frequency 50Hz, as in power supply stations, indoors and in cable ducts, outdoors, underground.
Construction
Conductor:Class 2 Aluminium conductor
Conductor:Semi-conductive shield
Insulation:Cross-Linked Polyethylene(XLPE)
Insulation shield:Semi-conductive shield
Metal shielding layer:Copper tape: 50-400mm Copper Wire: 500-800mm2
Binder tape:Non-woven fabrics
Isolation sleeve:Polyvinyl chloride(PVC)
Armour:Non-magnetic steel Tape
Outer sheath:Polyvinyl chloride (PVC)
Parameter
|
Specs
mm²
|
Conductor diameter
mm
|
Nominal thickness of insulation
mm
|
Outside diameter of insulation
±1.0mm
|
Nominal thickness of sheath
mm
|
Approximate outer diameter of cable
mm
|
Approximate cable weight
kg/km
|
|
1×50
|
8.2
|
10.5
|
31.6
|
2.3
|
44.1
|
2354
|
|
1×70
|
100
|
10.5
|
33.2
|
2.4
|
45.9
|
2551
|
|
1×95
|
11.6
|
10.5
|
35.0
|
2.4
|
47.7
|
2755
|
|
1×120
|
13.0
|
10.5
|
36.4
|
2.5
|
49.4
|
2953
|
|
1×150
|
14.4
|
10.5
|
37.8
|
2.5
|
51.0
|
3166
|
|
1×185
|
16.1
|
10.5
|
39.6
|
2.6
|
53.0
|
3425
|
|
1×240
|
18.4
|
10.5
|
41.8
|
2.6
|
55.2
|
3744
|
|
1×300
|
20.6
|
10.5
|
44.0
|
2.7
|
57.9
|
4135
|
|
1×400
|
23.4
|
10.5
|
46.8
|
2.8
|
60.9
|
4654
|
|
1×500
|
26.6
|
10.5
|
50.6
|
3.0
|
67.5
|
5647
|
|
1×630
|
30.0
|
10.5
|
54.0
|
3.1
|
71.3
|
6335
|
|
1×800
|
34.0
|
10.5
|
58.0
|
3.2
|
75.4
|
7146
|
FAQ
1.What types of cable products does your company primarily manufacture?
We specialize in the production of various types of power cables, control cables, communication cables, and specialty cables, including but not limited to PVC-insulated cables, XLPE power cables, mining cables, marine cables, and photovoltaic cables.
2.How do you ensure product quality for export?
We follow international standards (IEC, UL) and maintain strict quality control with regular inspections.
3. What payment methods are accepted for international orders?
We accept L/C, T/T, Western Union, PayPal, and bank transfers.
4. Can you provide samples before placing a large order?
Yes, we offer free samples for new customers to verify product quality.
5. How long is the typical delivery time for international orders?
Delivery times vary by destination, but we aim for 2-6 weeks for most orders.
6. Do you offer customization for special cable types?
Yes, we can customize cable specifications based on customer requirements.
